Precision Machine Vises, Specially Designed For Horizontal, Vertical Machining Centers!

• Horizontal Machining Centers
• Dimensions, Specifications of vises are specially designed for the Machine pallet size 500 x 500 and 630 x 630 mm
• Easier clamping operations with the lowest handle position (hydraulic)
• Mechanical clamping for deformable Work pieces at the top
• Main screw part enclosed against chips fall

• Vertical Machining Centers
• Less interferences with the machine table by vertical handle position
• Easier changes of Work pieces by PULL type mechanism

• Down thrust “Semi-Sphere-Segment” eliminates jaw lift and work lift
• Vise body is made of ductile iron (Tensile strength 60 Kgs mm2. All surface ground and vise bed flame hardened.
• Easier change of mode by original clutch mechanism

• All the vises are matched pair on the height of vise bed with the tolerance of +/- 20 microns
• Made of ductile iron, stress relieved by annealing, Vise bed is flame hardened.
• Semi-sphere segment mechanism eliminates jaw tilt and jaw lift
• Minimum bending of vise body
• Highest clamping power
• Rigid ductile iron body that never breaks
• Simple mechanism free from disorders
• Guaranteed accuracy
• Weight is 20% less compared with conventional type of easier handling and high speed feeding.

• Self-Cut Jaws for Aluminium Workpieces
• 2 Work pieces can be clamped at one time and shorten set-up time
• Sliding and fixed jaws are made of aluminium to reduce weight
• Sliding and fixed jaws can be machined (Self-cut) suitable for user’s Work pieces
• Easily detachable sliding jaws by spring plunger inside
• Can be changed to centering vises with standard accessory

• Specially designed constructions to avoid interferences with main spindle. Cutting tool lengths can be shorten to reduce production time.
• Anti-floating device. Minimized Work piece floating with Semi-Sphere segment construction
• Interchangeable jaw plates. Most suitable jaw plates can be selected for various kinds of machines.
• Work piece can be clamped at the center of Vise, which lead to easier programming.

• 4 different clamping positions of jaw plates to suit Work pieces
• Anti-floating device. Minimized Work piece floating with Semi-Sphere segment construction
• Interchangeable jaw plates. Most suitable jaw plates can be selected for various kinds of machines.

ETO- 80GTH	ETO-10G

• Free positioning of the nut block and sliding jaw with patented “Wedge-Lock” method
• Down-thrust access of the sliding jaw with clamping screw engaging the nut on the slant prevents jaw tilt and Work piece lift
• Easy set-up with Keyway
• Hardened tool steel ground to the highest degree of precision, parallel and square within 0.005 mm guaranteed

• For Grinding Application Only
• Highly economical without clamping opening and grooves
• Free positioning of the nut block and sliding jaw with patented “Wedge-Lock” method
• Hardened tool steel ground to the highest degree of precision, parallel and square within 0.005 mm guaranteed

• Can be used when user needs bigger opening which cannot be covered by ordinary machine vise
• Made of ductile iron and unbreakable construction
• Can clamp the Work piece down to the table
